Nephron Diagram: Labeled Structure and Function

Name: Nephron Diagram: Labeled Structure and Function
Creator: Dr. Zubair Khalid

By Dr. Zubair Khalid, DVM, MS, PhD · 2026-09-20

A nephron is the microscopic functional unit of the kidney, and every nephron diagram shows the same basic working parts: a renal corpuscle (glomerulus plus Bowman's capsule), a proximal convoluted tubule, a loop of Henle with descending and ascending limbs, a distal convoluted tubule, and a collecting duct that carries finished urine toward the renal pelvis. Each segment has a distinct job, and the length and number of these segments differ across species in ways that reflect where an animal lives and how much water it can afford to lose.

This guide walks through a labeled nephron, segment by segment, then puts the functions side by side in a table. It also covers how nephron anatomy varies between dogs, cats, horses, cattle, birds, desert mammals, and aquatic species, because a nephron diagram built only from human physiology misses much of what veterinary students need.

This article is educational and is not a substitute for veterinary diagnosis or treatment.

What Are Nephrons and Why They Are the Functional Unit of the Kidney

The kidney is a compound organ built from thousands to millions of repeated tubular units. Each unit filters blood plasma, reclaims most of what the body needs, secretes a smaller set of waste products and ions into the tubular fluid, and adjusts the final fluid volume and concentration before it leaves as urine. Because a single nephron can perform all four of those tasks, it is called the functional unit of the kidney. The rest of the organ (interstitium, blood vessels, calyces, pelvis, and in mammals the renal capsule) exists to support, drain, and package what the nephrons produce.

Nephron anatomy follows a consistent plan across mammals and birds, with important variation in the middle segment. Blood enters the renal corpuscle through an afferent arteriole, passes through a tuft of capillaries called the glomerulus, and exits through an efferent arteriole. The glomerulus sits inside a cup-shaped epithelial sac, Bowman's capsule. Fluid filtered from the capillaries crosses three layers (fenestrated endothelium, glomerular basement membrane, and podocyte foot processes) and enters the capsular space. From there, fluid flows through the tubule segments in a fixed order. The tubule is lined by a single layer of epithelial cells whose shape, transporter profile, and permeability change from segment to segment. That changing epithelium is what makes each part of the nephron do a different job.

Nephrogenesis, the process that builds nephrons, depends on a pool of stem-like nephron progenitor cells. Epigenetic regulation of those progenitors affects their self-renewal and their differentiation into the precursors of each mature nephron segment, and it also contributes to the age-related cessation of nephrogenesis, which sets the final nephron endowment of the kidney [1]. In most mammals this process is largely complete before or shortly after birth, so the number of nephrons an animal ends up with is set early in life.

A Labeled Nephron: Segment by Segment

The list below follows the path of fluid from blood to urine. Each numbered item corresponds to a structure a student should be able to point to on a labeled nephron diagram.

Afferent arteriole. Delivers blood to the glomerular capillary tuft. Its diameter influences glomerular capillary pressure and therefore filtration rate.
Glomerulus. A ball of fenestrated capillaries where plasma is filtered. The filtration barrier retains cells and most large proteins while letting water and small solutes pass.
Bowman's capsule. The epithelial cup surrounding the glomerulus. Its inner (visceral) layer is made of podocytes, and its outer (parietal) layer is simple squamous epithelium. The space between them, the capsular space, receives the filtrate. Together the glomerulus and Bowman's capsule form the renal corpuscle.
Proximal convoluted tubule (PCT). The first tubular segment, lined by cuboidal epithelial cells with a prominent brush border of microvilli. The brush border greatly expands surface area for reabsorption. This is the busiest reabsorptive segment of the nephron.
Loop of Henle, descending limb. A thin segment that dips into the renal medulla. It is highly permeable to water and relatively impermeable to solutes, so water leaves the tubule as the fluid descends into the increasingly concentrated medullary interstitium.
Loop of Henle, ascending limb. Returns fluid toward the cortex. It is impermeable to water and actively transports sodium, potassium, and chloride out of the tubular fluid. The thick ascending limb is the classic site of action of loop diuretics.
Distal convoluted tubule (DCT). A shorter, less convoluted segment in the cortex. It fine-tunes sodium, potassium, and calcium reabsorption under hormonal control and is a major site of calcium regulation.
Collecting duct. Not strictly part of a single nephron in the embryological sense, but functionally the final common pathway. Several nephrons drain into one collecting duct, which runs through the medulla to the renal papilla. Its water permeability is hormone-controlled, which is what allows the kidney to produce concentrated or dilute urine.

The renal corpuscle, PCT, and DCT sit in the renal cortex. The loop of Henle and the collecting duct extend into the medulla. That cortical-medullary arrangement is what allows the kidney to build an osmotic gradient and concentrate urine, and it is the reason the length of the loop matters so much across species.

Table of Segment Functions: Filtration, Reabsorption, Secretion, and Concentration

The table below summarizes what each nephron segment does. Percentages are approximate textbook values for the fraction of filtered water or solute handled by each segment and are intended as study anchors rather than exact species-specific figures.

Segment	Primary process	What moves	Direction	Notes
Glomerulus and Bowman's capsule	Filtration	Water, ions, glucose, amino acids, urea, small solutes	Blood to capsular space	Size and charge selective. Cells and most plasma proteins are retained.
Proximal convoluted tubule	Reabsorption (major) and secretion	Roughly 65 to 70 percent of filtered water and sodium, nearly all glucose and amino acids, most bicarbonate	Tubule to blood (reabsorption). Some organic acids and bases move blood to tubule (secretion).	Brush border and dense mitochondria support high transport capacity.
Loop of Henle, descending limb	Passive water movement	Water	Tubule to interstitium	Permeable to water, not to solutes. Fluid becomes more concentrated as it descends.
Loop of Henle, ascending limb	Active solute reabsorption	Sodium, potassium, chloride	Tubule to interstitium	Impermeable to water. Dilutes tubular fluid and contributes to the medullary gradient.
Distal convoluted tubule	Regulated reabsorption and secretion	Sodium, calcium, potassium	Both directions depending on hormone signals	Fine-tuning segment. Sensitive to parathyroid hormone and aldosterone.
Collecting duct	Concentration and final adjustment	Water (hormone-dependent), sodium, potassium, urea	Both directions	Final site of urine concentration. Water permeability is controlled by antidiuretic hormone or arginine vasotocin.

Read the table as a flow: filtration loads the tubule, the PCT reclaims the bulk, the loop builds the concentration gradient, the DCT fine-tunes electrolytes, and the collecting duct decides how much water leaves with the urine.

Filtration at the Renal Corpuscle

Filtration is the first step and the one that sets the workload for everything downstream. Blood pressure in the glomerular capillaries pushes water and small solutes through the filtration barrier. The barrier is selective in two ways. Size selectivity excludes cells and large proteins. Charge selectivity makes the barrier less permissive to negatively charged molecules, which is why loss of the negatively charged glycocalyx can allow albumin to leak into the filtrate in early kidney disease.

The rate at which filtration occurs is the glomerular filtration rate, usually abbreviated GFR. GFR depends on the balance of pressures across the filtration barrier and on the total surface area available for filtration. Because surface area depends on the number of functioning glomeruli, nephron number and GFR are linked. Loss of nephrons reduces filtration capacity, and the remaining nephrons compensate by increasing their individual workload.

Nephron number varies widely across species. In a rabbit model, automated MRI-based counting identified a mean of 170,972 glomeruli in control animals at six weeks of age [2]. That single figure illustrates how large the nephron endowment is in a small mammal and how much it can be affected by early-life events. In the same study, rabbits exposed to nephrotoxins during early postnatal nephrogenesis developed acute kidney injury, and those exposed later had a measurable reduction in glomerular number compared with controls [2]. The takeaway for veterinary students is that nephron endowment is not fixed at conception. It is set during a developmental window, and insults during that window can leave a lasting mark on kidney structure.

Reabsorption: Reclaiming What the Body Needs

Reabsorption is the movement of filtered substances from the tubular fluid back into the blood. It happens in every tubular segment, but the proximal convoluted tubule does the heavy lifting. Roughly two thirds of filtered water and sodium are reabsorbed there, along with nearly all of the filtered glucose and amino acids. The PCT is built for this job. Its cells have a dense brush border, abundant mitochondria, and a high density of transporters on both the apical (luminal) and basolateral (blood-facing) membranes.

The molecular details of proximal reabsorption are well characterized. In mice, the transporter SLCO4A1 localizes to the basolateral membrane of multiple renal tubular epithelial cells, and deleting it increases urine output and sodium excretion while reducing sodium reabsorption across several nephron segments [3]. Loss of SLCO4A1 was accompanied by downregulation of key sodium transporters and channels, including SGLT2, NHE3, NKCC2, NCC, and ENaC, which are distributed across the proximal tubule, thick ascending limb, distal convoluted tubule, and collecting duct [3]. Overexpressing the transporter produced the opposite effect. This study shows that sodium handling is not the property of one segment alone. It is coordinated across the whole nephron.

The loop of Henle continues reabsorption, but with a twist. The descending limb lets water leave passively, concentrating the fluid inside the tubule. The ascending limb is impermeable to water and pumps sodium, potassium, and chloride out into the interstitium. The result is a countercurrent multiplier: fluid leaving the loop is more dilute than the fluid entering it, while the medullary interstitium becomes more concentrated. That interstitial gradient is the engine that later allows the collecting duct to pull water out of urine.

The distal convoluted tubule handles a smaller volume but does so under tight hormonal control. It reabsorbs sodium and calcium and secretes potassium, and its activity is adjusted by aldosterone and parathyroid hormone. The distal convolution, which includes the DCT and the connecting tubule, is also the main site of Klotho expression in the kidney. Work in mice showed that the late DCT and connecting tubule produce about 80 percent of urinary soluble Klotho, with the remaining 20 percent coming from the DCT proper [4]. Deleting Klotho in the distal convolution suppressed signaling through the mitogen-activated protein kinase pathway and downregulated several genes involved in kidney calcium handling, including Trpv5, Vdr, Pth1r, and Klk1 [4]. This is a good example of how a segment that handles a small fraction of total sodium can still be central to mineral homeostasis.

Secretion: Moving Substances Into the Tubule

Secretion is the opposite of reabsorption. It moves substances from the blood into the tubular fluid so they can be excreted. The proximal tubule is the main site of secretion for organic acids, organic bases, and a range of drugs and metabolites. Secretion is how the kidney eliminates protein-bound compounds that filtration cannot remove, because only free (unbound) molecules pass the glomerular barrier.

Secretion also matters clinically. Many drugs are actively secreted into the proximal tubule, and competition for the same transporters can change how long a drug stays in the body. This is one reason kidney function affects drug dosing in veterinary patients. The distal nephron also secretes potassium and hydrogen ions, which is how the kidney fine-tunes acid-base balance.

Concentration: Making Urine Stronger Than Plasma

Concentration is the process that lets an animal produce urine more concentrated than its own blood plasma. It depends on two things working together: the medullary osmotic gradient built by the loop of Henle, and the hormone-controlled water permeability of the collecting duct.

The collecting duct is where the final decision is made. Its cells express water channels called aquaporins. In mammals, antidiuretic hormone (ADH, also called vasopressin) inserts aquaporin 2 channels into the apical membrane, allowing water to move out of the duct into the concentrated medulla. In birds, the equivalent hormone is arginine vasotocin (AVT). A comparative study of marine and terrestrial birds found that water inflow in collecting duct epithelial cells is controlled by aquaporin 2 and an AVT-sensitive water channel expressed along cortical and medullary collecting ducts [5]. Birds are the only non-mammalian vertebrates that can concentrate their urine, and that ability is tied to this hormone-channel system [5].

When ADH or AVT is high, the collecting duct reclaims water and urine becomes concentrated. When it is low, the duct stays relatively impermeable and dilute urine is produced. This is why an animal that has been deprived of water produces small volumes of concentrated urine, while an animal that has drunk heavily produces large volumes of dilute urine.

Species Differences in Nephron Anatomy

A nephron diagram drawn from a dog or a human is a starting point, not a universal template. Two variables change the most across species: the length of the loop of Henle and the total number of nephrons.

Loop of Henle Length and Habitat

Loop length tracks water availability. Desert mammals such as kangaroo rats and jerboas have very long loops of Henle that extend deep into the medulla. Long loops build a steeper osmotic gradient, which allows the collecting duct to reclaim more water and produce highly concentrated urine. This is a direct adaptation to habitats where water is scarce.

Aquatic mammals and animals with constant access to fresh water tend to have shorter loops. A shorter loop builds a shallower gradient, which limits how concentrated urine can become but is adequate when water is abundant. The trade-off is efficiency versus water conservation. An animal that can produce extremely concentrated urine can survive on less water, but building and maintaining a deep medullary gradient costs energy.

Birds show the same principle in a different architecture. The comparative study of mallard ducks (marine habitat) and domestic chickens (terrestrial habitat) found that the mallard renal lobule had a proportionally longer medulla (about 30 percent) and cortex (about 70 percent), while the chicken had a much larger cortical region (about 85 percent) and a smaller medullary region (about 15 percent) [5]. The mallard also had more abundant cortical reptilian nephrons, while the chicken had more mammalian-type nephrons [5]. This is a clear example of habitat shaping nephron and kidney architecture within the same vertebrate class.

Nephron Number Across Species

Nephron number varies enormously. Small mammals tend to have fewer nephrons than large mammals in absolute terms, but the relationship is not simple, because metabolic rate, kidney size, and body mass all interact. The rabbit figure of roughly 171,000 glomeruli per kidney [2] gives one concrete anchor point for a medium-sized laboratory mammal. A large dog or a horse will have far more, and a mouse will have far fewer, but the exact numbers depend on the study and the counting method.

What matters for veterinary practice is that nephron number is set early and is a major determinant of renal reserve. Animals born with fewer nephrons, or animals that lose nephrons to injury, have less reserve to draw on later in life. Maternal protein restriction in rats, for example, is associated with reduced nephron number early in life plus renal dysfunction and hypertension in adulthood, and a proteomic study of aged male rats exposed to maternal protein restriction found persistent renal impairment with increased serum creatinine and tubular congestion [6]. Early-life nutrition and early-life injury both leave lasting structural footprints on the kidney.

Clinical Relevance, Limitations and Common Mistakes

Understanding nephron anatomy changes how you interpret clinical data. Serum creatinine and blood urea nitrogen (BUN) are markers of filtration function, and they rise only after a substantial fraction of nephron function is lost. In the rabbit nephrotoxicity study, late-exposed animals had elevated BUN and serum creatinine relative to early-exposed animals, and the late-exposed group also had a measurable reduction in glomerular number [2]. This is the pattern clinicians see in practice: structural loss shows up as a functional change on bloodwork, but only after compensation fails.

Nephron injury is also segment-specific. Ischemic injury in human kidney organoids caused loss of cell type-specific markers and key functional genes across nephron segments, and after recovery, podocyte and distal tubule markers were largely restored while proximal tubule markers showed only partial recovery [7]. The proximal tubule is metabolically demanding and vulnerable, which is why it is often the first segment to show damage in ischemic and toxic injury. This is also why drugs that are secreted or reabsorbed in the proximal tubule can be nephrotoxic at high doses.

Common mistakes students and clinicians make:

Treating all nephrons as identical. Cortical and juxtamedullary nephrons differ in loop length and blood supply, and they contribute differently to concentration.
Assuming the collecting duct is part of one nephron. Functionally it is the final common pathway for many nephrons, and its behavior is regulated separately from the tubule that feeds it.
Forgetting that nephron number is set early. An animal with reduced nephron endowment may look normal for years before compensation fails.
Ignoring species differences in loop length. A drug or fluid protocol developed for one species may not translate directly to a desert-adapted or aquatic species.
Confusing filtration rate with nephron number. GFR reflects the combined function of all filtering nephrons, plus the compensatory increase in single-nephron filtration when nephrons are lost.

Individual cases need a veterinarian. Bloodwork trends, imaging, and urinalysis together give a far better picture than any single number.

Frequently Asked Questions

What are nephrons?

Nephrons are the microscopic functional units of the kidney. Each nephron filters blood plasma, reabsorbs needed substances, secretes waste products, and adjusts the final urine concentration.

What are the main parts of a nephron?

The main parts are the renal corpuscle (glomerulus and Bowman's capsule), the proximal convoluted tubule, the descending and ascending limbs of the loop of Henle, the distal convoluted tubule, and the collecting duct.

What does the proximal convoluted tubule do?

The proximal convoluted tubule reabsorbs the majority of filtered water and sodium, along with nearly all filtered glucose and amino acids. It also secretes organic acids, bases, and many drugs into the tubular fluid.

What is the difference between the descending and ascending limbs of the loop of Henle?

The descending limb is permeable to water and lets water leave the tubule. The ascending limb is impermeable to water and actively pumps sodium, potassium, and chloride out, which dilutes the tubular fluid and builds the medullary gradient.

Why do desert animals have longer loops of Henle?

Longer loops build a steeper osmotic gradient in the medulla, which lets the collecting duct reclaim more water. That allows desert animals to produce highly concentrated urine and survive on limited water.

Do all animals have the same number of nephrons?

No. Nephron number varies widely across species and even within a species. It is set largely during development, and early-life injury or nutritional stress can reduce the final number.

How does the collecting duct concentrate urine?

The collecting duct concentrates urine by allowing water to leave the duct into the concentrated medulla. This water movement depends on aquaporin channels that are controlled by antidiuretic hormone in mammals and arginine vasotocin in birds.

Why is the nephron called the functional unit of the kidney?

The nephron is called the functional unit because it performs all four core kidney tasks: filtration, reabsorption, secretion, and concentration. The rest of the kidney supports and drains what the nephrons produce.
