What Is a Karyotype? Definition, Uses, and How to Read One

By Dr. Zubair Khalid, DVM, MS, PhD · 2026-09-20

A karyotype is the ordered display of an organism's metaphase chromosomes, arranged by size, centromere position, and banding pattern. It is the classic cytogenetic snapshot of a genome, and it remains the only routine test that shows every chromosome at once, in a single cell, at a resolution of roughly 5 to 10 megabases.

That last property is why karyotyping still matters in 2026. Sequencing tells you the letters. A karyotype tells you whether the chromosomes carrying those letters are present in the right number, whether they are intact, and whether pieces of one have moved to another. Balanced translocations, ring chromosomes, inversions, and low-level mosaicism are all visible on a banded metaphase spread, and several of these are invisible to standard short-read sequencing [1]. A karyotype is also the foundation of reproductive genetics, cancer cytogenetics, prenatal diagnosis, and livestock breeding programs.

Definition and Key Terms

A karyotype is the chromosome complement of a cell or organism, described by the total number of chromosomes and their morphology. The related term karyogram (or idiogram) refers to the arranged image itself, with homologs paired and laid out in a standard order.

Several terms appear constantly in karyotype reports. Learn them before reading a single band.

Metaphase: the stage of mitosis when chromosomes are maximally condensed and individually visible. Karyotyping targets this stage.
Centromere: the constriction where sister chromatids join and where the spindle attaches. Its position defines chromosome shape.
Metacentric: centromere near the middle, so the two arms are roughly equal.
Submetacentric: centromere offset, producing one clearly longer arm.
Acrocentric: centromere very near one end, leaving a tiny short arm. Human chromosomes 13, 14, 15, 21, and 22 are acrocentric.
p arm and q arm: the short and long arms, from the French petit and queue.
Banding pattern: the reproducible light and dark stripes produced by staining, which allow individual chromosomes to be identified and matched.
Ploidy: the number of chromosome sets. Humans are diploid, written 2n = 46.
Aneuploidy: an abnormal number of individual chromosomes, such as trisomy 21.
Mosaicism: two or more cell lines with different karyotypes in the same individual, usually from a post-zygotic error [2].

Karyotype versus related tests

Feature	Karyotype (G-banding)	FISH	Chromosome microarray
What it detects	Number, structure, and arrangement of all chromosomes	Presence, number, or location of a specific DNA sequence	Copy number gains and losses across the genome
Resolution	Roughly 5 to 10 Mb	Probe-dependent, often 100 kb to 1 Mb	Often below 100 kb
Balanced rearrangements	Yes	Only if targeted	No
Mosaicism	Yes, if enough cells are counted	Yes, on interphase nuclei	Limited
Throughput	Low, manual	Medium	High
Typical use	Constitutional and cancer cytogenetics	Confirming marker chromosomes, HER2 status	Prenatal and developmental delay workup

The trade-off is fundamental. Microarray detects smaller imbalances than karyotyping but cannot see a balanced translocation, because no DNA is gained or lost. A large prenatal study of 2,860 pregnancies found that chromosome microarray detected clinically relevant variants in 14.41% of cases versus 10.10% for G-banded karyotyping, with the highest yield in fetuses that had structural anomalies [3]. The two tests answer different questions and are frequently run together.

The Laboratory Workflow, Step by Step

The steps below are the standard short-term culture protocol used for peripheral blood, bone marrow, amniocytes, and solid tissue. Each step exists for a specific physical reason.

1. Sample collection

Peripheral blood drawn into a heparin tube is the usual specimen for constitutional studies. Bone marrow aspirate is used for hematologic malignancy. Amniotic fluid or chorionic villi are used prenatally. Solid tissues such as skin fibroblasts or tumor biopsies require enzymatic disaggregation first. Heparin matters because it prevents clotting and does not interfere with lymphocyte viability.

2. Cell culture

Cells are grown in complete medium with a mitogen. For blood, phytohemagglutinin stimulates T lymphocytes to divide. Cultures typically run 48 to 72 hours, and a 72-hour culture is standard for routine blood karyotyping [4]. Prenatal and fibroblast cultures take longer, often one to two weeks, because the starting cell number is small and the population must expand.

3. Mitotic arrest

A spindle poison such as colcemid or colchicine is added for a short period, usually 15 to 60 minutes. This depolymerizes microtubules and blocks cells in metaphase, when chromosomes are condensed and countable. Timing is the single most important variable in the whole protocol. Too short and few metaphases are captured. Too long and chromosomes over-condense into short, poorly banded stubs.

4. Hypotonic treatment

A dilute salt solution, classically 0.075 M potassium chloride, is added. Water enters the cells osmotically, the cells swell, and the chromosomes spread apart. Without this step, chromosomes remain clumped and overlap. With too much, chromosomes burst and scatter.

5. Fixation

The swollen cells are dropped into methanol and acetic acid, usually in a 3:1 ratio. Fixative removes water, hardens the chromosomes, and preserves morphology. Cells are washed in fresh fixative two or three times to remove cytoplasmic debris.

6. Slide preparation and aging

The cell suspension is dropped onto a clean slide from a height, and the fixative evaporates, flattening the chromosomes onto the glass. Slides are then aged, either overnight at room temperature or briefly on a hot plate, which improves banding quality.

7. Staining and banding

Giemsa staining alone gives solid-colored chromosomes and is enough to count them and see centromere position [5]. For identification of individual chromosomes, G-banding (Giemsa banding) is used. Slides are treated briefly with trypsin, which digests a fraction of chromosomal protein, then stained with Giemsa. The result is a reproducible pattern of dark (A-T rich, gene-poor) and light (G-C rich, gene-rich) bands. Trypsin digestion time controls band contrast, and it is the step most often adjusted when banding looks poor.

Alternative banding methods include C-banding, which stains constitutive heterochromatin, typically at centromeres, and Q-banding with quinacrine, which produces fluorescent bands [5][6]. Silver staining highlights nucleolar organizer regions, the sites of ribosomal RNA genes [6].

8. Microscopy, capture, and assembly

A cytotechnologist scans the slide for well-spread, non-overlapping metaphases. Each chromosome is captured digitally, then paired with its homolog and arranged by size and centromere position. Modern laboratories increasingly use automated detection and pairing. A 2026 deep learning pipeline combining YOLOv8 detection with ResNet-50 classification reached 98.03% detection accuracy and 94.01% validation accuracy for homologous-pair assignment across 24 chromosome classes [7]. These tools speed up assembly but do not replace expert review of the final image.

flowchart TD
    A[Collect sample] --> B[Culture cells]
    B --> C[Arrest in metaphase]
    C --> D[Hypotonic swelling]
    D --> E[Fix and drop slides]
    E --> F[Trypsin and Giemsa stain]
    F --> G[Capture metaphase images]
    G --> H[Pair homologs and assemble]
    H --> I[Count chromosomes]
    I --> J[Identify sex chromosomes]
    J --> K[Scan for structural changes]
    K --> L[Report in ISCN]

How to Read a Karyotype

Reading a karyotype follows a fixed order. Do not jump to the bands first. Count, then identify the sex chromosomes, then look for structure.

Step 1: Count the chromosomes

Count the total number of centromeres, not the number of chromatid arms. A normal human karyotype has 46. Any deviation is the first finding to report. Count at least 20 metaphases in a routine study, and 30 or more when mosaicism is suspected, because a low-level second cell line can be missed in a small sample.

Step 2: Identify the sex chromosomes

Human autosomes are numbered 1 through 22. The remaining pair is the sex chromosomes. A normal female is 46,XX. A normal male is 46,XY. Confirm sex chromosome identity by banding pattern, not just by size, because the X and some autosomes are similar in length.

Step 3: Check chromosome morphology

For each pair, confirm the centromere position. A chromosome that should be metacentric but appears acrocentric suggests a rearrangement. Compare arm lengths between homologs. A visible size difference between the two members of a pair suggests a deletion or duplication, though small imbalances fall below the resolution of light microscopy.

Step 4: Scan the banding pattern

Read each chromosome from pter (the tip of the short arm) to qter (the tip of the long arm). Band numbering runs outward from the centromere. For example, 17q12 means chromosome 17, long arm, region 1, band 2. Compare the band sequence of the two homologs. A missing band, an extra band, or a band in the wrong place indicates a structural change.

Step 5: Look for extra or missing material

Free fragments, small extra chromosomes, and unusual derivative chromosomes are the classic structural findings. A small supernumerary marker chromosome (sSMC) is an extra chromosome fragment, generally no larger than chromosome 20 at metaphase, whose origin cannot be determined by G-banding alone [4]. These require FISH or microarray to characterize, and their clinical significance ranges from benign to severe depending on gene content [8][4].

Step 6: Apply ISCN nomenclature

The International System for Human Cytogenomic Nomenclature (ISCN) is the standard language for writing karyotypes. It has a fixed grammar: total chromosome count, comma, sex chromosomes, comma, abnormalities in order of chromosome number. Learning to read it is the difference between a picture and a report.

Common Abnormalities and Their Notation

The table below covers the abnormalities you will meet most often. Notation follows ISCN conventions.

Abnormality	Definition	Example notation	Notes
Trisomy	One extra copy of a chromosome	47,XX,+21	Down syndrome. Three copies of chromosome 21
Monosomy	One missing copy of a chromosome	45,X	Turner syndrome. Full autosomal monosomy is usually lethal
Deletion	Loss of a chromosome segment	46,XY,del(5)(p15.2)	Terminal or interstitial. Cri-du-chat involves 5p
Duplication	Extra copy of a segment	46,XX,dup(9)(q21.11q22.32)	Tandem or inserted. Often detected by microarray [9]
Inversion	Segment flipped end to end	46,XY,inv(9)(p11q13)	Paracentric excludes centromere, pericentric includes it
Reciprocal translocation	Exchange between two chromosomes	46,XX,t(1;6;14)	Balanced carriers are usually phenotypically normal [10]
Ring chromosome	Chromosome ends fuse into a circle	46,X,r(X)(p11.22q13.23)	Often unstable and mosaic [2]
Isochromosome	Mirror-image chromosome from centromere misdivision	46,X,i(Xq)	Common in Turner variants
Marker chromosome	Extra fragment of unknown origin	47,XY,+mar	Requires FISH or microarray [8][4]
Mosaicism	Two or more cell lines	mos45,X/46,X,r(X)	Brackets give cell counts per line [2]

Note the bracket convention. In mos45,X/46,X,r(X)(p11.22q13.23), the numbers in brackets are the number of cells observed with each karyotype, so 170 cells were 45,X and 30 carried the ring X [2]. This is how mosaicism is quantified in a report.

Uses Across Biology and Medicine

Constitutional and prenatal diagnosis

Karyotyping is a first-tier test for suspected aneuploidy, recurrent pregnancy loss, and ambiguous genitalia. In prenatal settings it is combined with microarray and FISH. A case of a fetus flagged by non-invasive prenatal testing for a sex chromosome abnormality was resolved only by combining G-banding, FISH, and copy number variation sequencing, which together identified a complex 45,X/46,X,dic r(Y;Y)/46,X,r(Y) karyotype [11]. No single method would have produced the full picture.

Cancer cytogenetics

Tumor karyotypes are often wildly abnormal, with gains, losses, and multiple rearrangements. G-banding is uniquely suited to tracking how a clone evolves over time, because it analyzes whole chromosomes in single cells. Investigators have used serial G-banding to build phylogenetic trees of karyotype evolution in myelodysplastic syndrome and acute myeloid leukemia with TP53 mutations, and separately in multiple myeloma [12][13]. In both studies, the trees revealed branched, linear, and parallel evolutionary paths that a single snapshot could not show.

Radiation biodosimetry

Stable translocations persist for years after radiation exposure, which makes them useful for retrospective dose reconstruction. In six victims of a cobalt-60 accident, G-banding analysis of translocations at 9 and 20 years after exposure showed a significant dose-effect relationship, and dose estimates from translocations matched those originally derived from dicentrics and rings measured 5 days after the event [14]. This is a rare application where a decades-old sample still yields quantitative data.

Veterinary and comparative cytogenetics

Karyotyping underpins livestock breeding and companion animal genetics. Chromosome number and morphology are used to confirm species, screen breeding animals for translocations that cause infertility, and characterize hybrids. In wildlife and comparative work, banding and Zoo-FISH reveal conserved synteny across species. A detailed study of the aardwolf found 2n = 40 with banding patterns largely conserved relative to the spotted hyena, and cat-aardwolf chromosome painting showed extensive conserved synteny, with differences limited to heterochromatic additions on a few chromosomes [15]. Similar work in the Indochinese shrew used GTG-banding to establish 2n = 38 and FN = 56, and to show that the species differs from close relatives mainly by a single fusion or fission event and a centromeric shift [16]. In fish, conventional karyotyping combined with FISH for ribosomal and telomeric repeats has been used to characterize invasive species such as Pseudorasbora parva, which shows 2n = 50 [6]. In insects, conventional staining and C-banding established 2n = 40 with an Xyp sex system in the flea beetle Podagrica fuscicornis [5].

Resolution Limits and When to Add Another Test

Routine G-banded karyotyping resolves changes of roughly 5 to 10 Mb. Anything smaller is below the limit of the light microscope. This is the single most important limitation to internalize.

Three consequences follow.

First, microdeletions and microduplications are missed. A 1.47 Mb duplication at 12p11.21 was invisible on G-banding and was found only by copy number variation sequencing [4]. In the prenatal cohort cited earlier, 61.33% of pathogenic copy number variants were under 5 Mb, and 54.00% were microdeletions [3].

Second, marker chromosomes cannot be resolved. G-banding identifies that an extra fragment exists but not what it contains. FISH with targeted probes or microarray is required to determine origin and gene content [8][4].

Third, balanced rearrangements are invisible to microarray but visible to karyotyping. This is the reciprocal limitation, and it is why the two tests are complementary rather than competing. A complex three-way translocation involving chromosomes 1, 6, and 14 was detected by high-resolution G-banding in a woman with eight years of primary infertility, and the same rearrangement was found in her phenotypically normal mother [10]. Microarray would have reported a normal result in both individuals.

Common Mistakes and Limitations

Counting chromatids instead of centromeres. A metaphase chromosome has two sister chromatids joined at one centromere. Counting arms doubles the chromosome number. Count centromeres.

Reading a karyotype without checking cell counts. A report that says mos means mosaicism, and the bracketed numbers tell you how many cells carried each line. Ignoring them hides the difference between a 5% mosaic and a 95% mosaic.

Assuming a balanced translocation is harmless. Balanced carriers are often phenotypically normal, but they can produce unbalanced gametes and are at increased risk for recurrent pregnancy loss and affected offspring [10]. The finding is clinically important even when the person is healthy.

Treating a normal karyotype as a normal genome. A normal G-banded karyotype rules out large numerical and structural changes. It does not rule out single-gene disorders, microdeletions, or point mutations.

Overlooking low-level mosaicism. Twenty cells is the routine count. A second cell line present at 5% will often be missed. When mosaicism is clinically suspected, more cells must be scored, and a second tissue may be needed.

Confusing ISCN order. Abnormalities are listed in a defined order, and the sex chromosomes always follow the total count. A misplaced comma changes the meaning.

Assuming all chromosomes band equally well. Terminal regions and the short arms of acrocentric chromosomes are poorly banded and easy to misread. Poor trypsin timing degrades the whole slide.

Individual results always require interpretation by a clinical geneticist or veterinarian in the context of the patient, not by the report alone.

Quick Review

A karyotype is the ordered display of metaphase chromosomes by size, centromere position, and banding pattern.
The workflow is collect, culture, arrest in metaphase, hypotonic swell, fix, drop, band, and assemble.
G-banding uses trypsin digestion followed by Giemsa to produce reproducible dark and light bands.
Read in order: count chromosomes, identify sex chromosomes, check morphology, scan bands, then apply ISCN.
Resolution is roughly 5 to 10 Mb, so microdeletions and marker chromosomes need FISH or microarray.
Balanced translocations and inversions are visible on karyotype but not on microarray.
Mosaicism is written with bracketed cell counts, as in mos45,X/46,X,r(X).

Frequently Asked Questions

What is a karyotype in simple terms?

A karyotype is a picture of all the chromosomes in a cell, sorted by size and shape and lined up in pairs. It shows how many chromosomes are present and whether any are structurally abnormal.

How long does a karyotype test take?

Blood cultures typically run 48 to 72 hours before harvest, and analysis adds several more days. Prenatal and solid tissue cultures can take one to two weeks because the cells must expand first.

What is the difference between a karyotype and a microarray?

A karyotype shows chromosome number and structure at roughly 5 to 10 Mb resolution, including balanced rearrangements. A microarray detects much smaller copy number gains and losses but cannot see balanced changes.

Can a karyotype detect Down syndrome?

Yes. Down syndrome is caused by trisomy 21 and appears as 47,XX,+21 or 47,XY,+21 on a standard karyotype.

What does mosaicism mean on a karyotype report?

Mosaicism means two or more cell lines with different chromosome constitutions exist in the same person. The bracketed numbers after each line show how many cells carried each karyotype.

Is a normal karyotype the same as a normal genome?

No. A normal karyotype rules out large numerical and structural chromosome changes. It does not rule out single-gene disorders, small copy number variants, or point mutations.
