Mycobacterium avium subsp. paratuberculosis (Johne's Disease): Etiology, Pathogenesis, Diagnostics, and Control
Introduction
Mycobacterium avium subsp. paratuberculosis (MAP) is the etiologic agent of paratuberculosis, also known as Johne's disease, a chronic granulomatous enteritis affecting primarily domestic and wild ruminants [1, 2]. The disease imposes substantial economic losses on the livestock industry, particularly dairy cattle, due to reduced milk production, premature culling, and decreased fertility [3, 4]. MAP is a fastidious, acid-fast, intracellular bacterium belonging to the Mycobacterium avium complex [5, 6]. Infection typically occurs in neonates via the fecal-oral route, followed by a prolonged subclinical phase that can last months to years before clinical signs emerge [2, 7]. The hallmark of clinical disease is chronic diarrhea, progressive emaciation, and eventual death [1, 2]. This article provides a detailed review of MAP biology, host-pathogen interactions, diagnostic approaches, genotyping methods, and control strategies, with emphasis on veterinary and molecular diagnostic perspectives.
Etiology and Taxonomy
MAP is a subspecies within the Mycobacterium avium complex, which also includes M. avium subsp. avium (causing avian tuberculosis) and M. avium subsp. hominissuis [8]. MAP is distinguished by its obligate dependence on mycobactin J for in vitro growth, a feature reflecting its iron acquisition deficiency [1, 9]. The genome of MAP strain K-10 has been fully sequenced, revealing a closed pangenome with limited genetic diversity compared to other mycobacteria [4, 2]. Two major strain types are recognized: cattle type (C-type) and sheep type (S-type), with additional bison type (B-type) strains described [10, 11]. These types differ in host preference, growth characteristics, and genomic markers such as IS900, IS1311, and long sequence polymorphisms (LSPs) [11, 8]. The S-type is further subdivided into type I and type III based on single nucleotide polymorphisms (SNPs) [10, 4].
Pathogenesis and Virulence Mechanisms
MAP enters the host via ingestion and translocates across the intestinal mucosa, primarily through M cells overlying Peyer's patches in the ileum [2]. The bacterium is phagocytosed by macrophages, its primary target cell, where it survives and replicates by inhibiting phagosome maturation and acidification [12, 5]. Key virulence factors include the type VII secretion system (ESX-5), lipoarabinomannan, and a family of serine proteases [5, 2]. MAP also modulates host cell signaling pathways, particularly through Toll-like receptor 2 (TLR2) activation, leading to upregulation of interleukin-10 (IL-10) via the mitogen-activated protein kinase (MAPK) p38 pathway [35]. IL-10 suppresses proinflammatory cytokine production and blocks phagosome maturation, facilitating intracellular survival [35]. Neutrophils are also recruited early in infection and can release extracellular traps (NETs) that immobilize and kill MAP, but this activity is inhibited in the presence of macrophages, suggesting a complex interplay that may contribute to chronic infection [12].
Host Immune Response
The host immune response to MAP is characterized by a transition from a Th1-dominant cell-mediated response in the subclinical stage to a Th2-dominant humoral response in the clinical stage [7]. During subclinical infection, antigen-specific interferon-gamma (IFN-γ) production by CD4+ T cells is prominent, along with tumor necrosis factor-alpha (TNF-α) and interleukin-2 (IL-2) [7]. As disease progresses, IL-10 and IL-12 levels increase, while IL-17A secretion declines [7]. Gene expression studies using RNA-Seq have identified dysregulation of the CXCL8/IL8 signaling pathway in both peripheral blood and ileocecal valve tissues of infected cattle [13]. Host genetic factors also influence susceptibility; polymorphisms in genes such as SLC11A1, NOD2, MHC-II, and TLRs have been associated with resistance or susceptibility to MAP infection across ruminant species [3]. The development of cytotoxic CD8+ T cells requires simultaneous cognate recognition of MAP epitopes by both CD4+ and CD8+ T cells, highlighting the importance of major histocompatibility complex (MHC) class I and II presentation [14].
Diagnostic Methods
Diagnosis of MAP infection is challenging due to the long subclinical phase and intermittent shedding of the organism [1, 6]. Diagnostic approaches can be categorized into direct detection (culture, molecular) and indirect detection (serology, cell-mediated immunity).
Culture
Culture is considered the gold standard for MAP detection, but it is time-consuming (up to 16 weeks) and requires specialized media supplemented with mycobactin J [1, 9]. Solid media (Herrold's egg yolk medium, Löwenstein-Jensen) and liquid media (BACTEC MGIT 960, Middlebrook 7H9) are used, with liquid systems offering faster detection [1]. Decontamination protocols are necessary for fecal and tissue samples to reduce competing microbiota [1]. Despite its specificity, culture sensitivity is limited, particularly for subclinical shedders [1, 9].
Molecular Detection
Polymerase chain reaction (PCR) targeting the multicopy insertion element IS900 is the most widely used molecular method [10, 6]. Real-time quantitative PCR (qPCR) targeting the f57 gene or ISMap02 provides improved specificity and quantification [6, 15]. Isothermal amplification methods, such as recombinase polymerase amplification combined with lateral flow dipstick (RPA-LFD), have been developed for rapid, point-of-care detection with sensitivity comparable to qPCR [16]. Peptide-mediated magnetic separation (PMS) coupled with phage assay allows detection of viable MAP in milk [17].
Serology
Enzyme-linked immunosorbent assays (ELISAs) detecting antibodies against MAP are commonly used for herd-level screening [18, 10]. Commercial ELISA kits are available for serum and milk samples [6, 19]. Seroprevalence studies in camels, sheep, goats, and cattle have demonstrated variable rates depending on geographic region and management practices [18, 10, 19]. However, ELISA sensitivity is low during early subclinical infection [6, 7].
Cell-Mediated Immunity
The IFN-γ release assay measures cell-mediated immune responses and can detect infection earlier than serology [20, 7]. Comparative studies in sheep, goats, and calves show species-specific differences in IFN-γ kinetics [20].
Diagnostic Workflow
The following Mermaid diagram illustrates a typical diagnostic decision tree for MAP infection in a herd.
flowchart TD
A[Clinical suspicion or herd screening], > B{Choose test type}
B, > C[Individual animal testing]
B, > D[Herd-level testing]
C, > E[Fecal sample]
C, > F[Blood/serum sample]
C, > G[Milk sample]
E, > H[PCR (IS900/f57) or culture]
F, > I[ELISA or IFN-gamma assay]
G, > J[Milk ELISA or qPCR]
H, > K{Result}
I, > K
J, > K
K, >|Positive| L[Confirm with alternative test]
K, >|Negative| M[Repeat testing or consider subclinical status]
L, > N[Management decision: cull, segregate, or vaccinate]
M, > O[Monitor herd prevalence]
D, > P[Bulk tank milk PCR/ELISA]
P, > Q[Estimate herd prevalence]
Q, > R[Implement control measures]
Genotyping and Molecular Epidemiology
Genotyping of MAP is essential for understanding transmission dynamics, tracing sources of infection, and differentiating strains [4, 8]. Methods include IS900 restriction fragment length polymorphism (RFLP), IS1311 PCR-restriction enzyme analysis (REA), multi-locus variable-number tandem repeat analysis (MLVA), and short sequence repeat (SSR) typing [11, 21, 22]. Whole-genome sequencing (WGS) provides the highest resolution and has revealed that MAP has a closed pangenome with limited SNP diversity [4]. WGS studies in France and Australia have identified distinct clades and demonstrated mixed infections within individual animals and herds [4, 11]. The web application MAC-INMV-SSR facilitates standardization and comparison of MLVA and SSR profiles across laboratories [21]. Genotyping has also confirmed the presence of MAP in wildlife species, including mongoose, red fox, and roe deer, indicating potential wildlife reservoirs [23, 24].
Epidemiology and Risk Factors
MAP infection is distributed worldwide, with herd-level prevalence often exceeding 50% in dairy regions [4, 25]. Risk factors include herd size, stocking density, introduction of infected animals, and management practices such as communal grazing and shared water sources [18, 25]. In camels, seroprevalence of 7.5% was reported in Egypt, with older age, diarrhea, and communal water as significant risk factors [18]. In Tunisian sheep, seroprevalence was 3.25%, with grazing and age influencing infection status [19]. Wildlife species, such as the Egyptian mongoose, can harbor MAP DNA, and ecological factors like altitude and temperature stability are associated with detection [23]. Free-living amoebae (e.g., Acanthamoeba castellanii) can serve as environmental reservoirs, supporting MAP survival and growth [26].
Control Strategies
Control of Johne's disease relies on test-and-cull programs, biosecurity, and vaccination [27, 28]. In New Zealand pastoral dairy herds, a combination of targeted culling of high shedders and calf management reduced seroprevalence from 26% to 2.3% over four years [27]. Vaccination with whole-cell killed vaccines reduces clinical disease and shedding but does not prevent infection and can interfere with tuberculosis diagnostics [2, 28]. In goats, vaccination induces adaptive immune responses that are influenced by the environment; test-and-cull strategies are not feasible in vaccinated herds using current serological tests [28]. Novel therapeutic approaches, such as synthetic cathelicidin LL-37, have shown promise in reducing MAP internalization and proinflammatory cytokine production in macrophages [29]. Natural antimicrobial compounds like cinnamon and oregano oils disrupt MAP cell membranes and may have potential as feed additives [30]. Copper ions have also been evaluated for reducing MAP viability in raw milk [31].
FAQ
What is the primary route of MAP transmission in ruminants?
The primary route is fecal-oral, with neonates ingesting the bacterium from contaminated colostrum, milk, or the environment [2, 27].
Why is MAP culture considered the gold standard despite its limitations?
Culture provides definitive evidence of viable MAP and allows for subsequent genotyping, but it is slow and has variable sensitivity depending on sample type and decontamination method [1, 9].
How does MAP survive inside macrophages?
MAP inhibits phagosome-lysosome fusion, resists acidification, and upregulates IL-10 production via TLR2-MAPK p38 signaling, thereby suppressing host antimicrobial responses [5, 35].
What is the difference between C-type and S-type MAP strains?
C-type (cattle type) strains are predominantly associated with cattle and are genetically monomorphic, while S-type (sheep type) strains are more diverse and commonly found in sheep and goats [10, 11]. Bison type (B-type) strains are also recognized [11].
Can MAP be detected in milk and milk products?
Yes, MAP DNA and viable cells have been detected in raw and pasteurized milk, powdered infant milk, and cheese using PCR and culture methods [32, 6, 33, 15]. Pasteurization reduces but does not eliminate MAP [6, 33].
What are the main challenges in controlling Johne's disease?
Challenges include the long subclinical period, lack of sensitive diagnostic tests for early infection, environmental persistence of MAP, and the presence of wildlife reservoirs [1, 23, 27].
References
[1] Dane H, Stewart L, Grant I. Culture of Mycobacterium avium subsp. paratuberculosis: challenges, limitations and future prospects. Journal of Applied Microbiology. 2022. URL: https://www.semanticscholar.org/paper/0bf023b96b04f10ddffff8d109613220f19cb398
[2] Rathnaiah G, Zinniel D, Bannantine J, et al. Pathogenesis, Molecular Genetics, and Genomics of Mycobacterium avium subsp. paratuberculosis, the Etiologic Agent of Johne’s Disease. Frontiers in Veterinary Science. 2017. URL: https://www.semanticscholar.org/paper/16b1f3a792fbeab7d4041f045507f3e5cf574bba
[3] Kravitz A, Pelzer K, Sriranganathan N. The Paratuberculosis Paradigm Examined: A Review of Host Genetic Resistance and Innate Immune Fitness in Mycobacterium avium subsp. Paratuberculosis Infection. Frontiers in Veterinary Science. 2021. URL: https://www.semanticscholar.org/paper/0fc1451478a3d3de67cb844030b21d6d21f1d282
[4] Conde C, Thézé J, Cochard T, et al. Genetic Features of Mycobacterium avium subsp. paratuberculosis Strains Circulating in the West of France Deciphered by Whole-Genome Sequencing. Microbiology spectrum. 2022. URL: https://www.semanticscholar.org/paper/8161413ed9376c062c8e75c4af7be9217720091f
[5] Ssekitoleko J, Ojok L, Abd El Wahed A, et al. Mycobacterium avium subsp. paratuberculosis Virulence: A Review. Microorganisms. 2021. URL: https://www.semanticscholar.org/paper/9c1812645aded9f5284ec7fe9a81472805e34639
[6] Hosseiniporgham S, Cubeddu T, Rocca S, et al. Identification of Mycobacterium avium subsp. paratuberculosis (MAP) in Sheep Milk, a Zoonotic Problem. Microorganisms. 2020. URL: https://www.semanticscholar.org/paper/08724afc7ac3f07831fcf98339f161052a3b3ba5
[7] Stabel J, Bannantine J. Divergent Antigen-Specific Cellular Immune Responses during Asymptomatic Subclinical and Clinical States of Disease in Cows Naturally Infected with Mycobacterium avium subsp. paratuberculosis. Infection and Immunity. 2019. URL: https://www.semanticscholar.org/paper/b37334919a0f0c9bb84e5f3422d405b5123ab6df
[8] Fawzy A, Zschöck M, Ewers C, et al. Genotyping methods and molecular epidemiology of Mycobacterium avium subsp. paratuberculosis (MAP). International Journal of Veterinary Science and Medicine. 2018. URL: https://www.semanticscholar.org/paper/f5524b78678f0ce2c7a35cbf4c8f81260b1524f0
[9] Whittington R, Behr M, Collins D. Cultivation of Mycobacterium avium subsp. paratuberculosis. Paratuberculosis: organism, disease, control. 2020. URL: https://www.semanticscholar.org/paper/dc5e151ad8809be93b8cbc850d4ae3c1642834d6
[10] Elsohaby I, Fayez M, Alkafafy M, et al. Serological and Molecular Characterization of Mycobacterium avium Subsp. paratuberculosis (MAP) from Sheep, Goats, Cattle and Camels in the Eastern Province, Saudi Arabia. Animals. 2021. URL: https://www.semanticscholar.org/paper/ba0fc4584b3ac313c3abc810e9c25ba0d543209a
[11] Hodgeman R, Mann R, Savin K, et al. Molecular characterisation of Mycobacterium avium subsp. paratuberculosis in Australia. BMC Microbiology. 2021. URL: https://www.semanticscholar.org/paper/3e65926e3ed11a48dd52cb22b79ca2397541b6fb
[12] Ladero-Auñon I, Molina E, Holder A, et al. Bovine Neutrophils Release Extracellular Traps and Cooperate With Macrophages in Mycobacterium avium subsp. paratuberculosis clearance In Vitro. bioRxiv. 2021. URL: https://www.semanticscholar.org/paper/bb4fb896ef1f467ad810f623852b7fcce0dbb1f3
[13] Alonso-Hearn M, Canive M, Blanco-Vazquez C, et al. RNA-Seq analysis of ileocecal valve and peripheral blood from Holstein cattle infected with Mycobacterium avium subsp. paratuberculosis revealed dysregulation of the CXCL8/IL8 signaling pathway. Scientific Reports. 2019. URL: https://www.semanticscholar.org/paper/d6ef953e2bbe9a001e99a0a8fdf5df981d2e7462
[14] Abdellrazeq GS, Fry LM, Elnaggar M, et al. Simultaneous cognate epitope recognition by bovine CD4 and CD8 T cells is essential for primary expansion of antigen-specific cytotoxic T-cells following ex vivo stimulation with a candidate Mycobacterium avium subsp. paratuberculosis peptide vaccine. Vaccine. 2020. URL: https://www.semanticscholar.org/paper/9b7aac3ae0d2f277406b07f764bfcf4993a5b2cf
[15] Hruška K, Slana I, Kralik P, et al. Mycobacterium avium subsp. paratuberculosis in powdered infant milk: F57 competitive real time PCR. 2018. URL: https://www.semanticscholar.org/paper/d565b2f099f507a8b8bb4b3f71e572d2690f20f0
[16] Zhao G, Wang H, Hou P, et al. Rapid visual detection of Mycobacterium avium subsp. paratuberculosis by recombinase polymerase amplification combined with a lateral flow dipstick. Journal of Veterinary Sciences. 2018. URL: https://www.semanticscholar.org/paper/81aed465de9d932515ee6fb871ec35856ed8dc64
[17] Foddai A, Grant IR. Sensitive and specific detection of viable Mycobacterium avium subsp. paratuberculosis in raw milk by the peptide‐mediated magnetic separation‐phage assay. Journal of Applied Microbiology. 2017. URL: https://www.semanticscholar.org/paper/1ec40d5f582c52ed5cbbd619cfab836247ec8565
[18] Selim A, Attia K, Alsubki R, et al. Cross-sectional survey on Mycobacterium avium Subsp. paratuberculosis in Dromedary Camels: seroprevalence and risk factors. Acta Tropica. 2021. URL: https://www.semanticscholar.org/paper/318b1d26e8548fa9b3554973076d59f64527eae0
[19] Khamassi Khbou M, Romdhane R, Sassi L, et al. Seroprevalence of anti‐Mycobacterium avium subsp. paratuberculosis antibodies in female sheep in Tunisia. Veterinary Medicine and Science. 2019. URL: https://www.semanticscholar.org/paper/d4cf9ac2896aaa526ce370f9fa3e4720403855f4
[20] Stabel J, Bannantine J, Hostetter J. Comparison of Sheep, Goats, and Calves as Infection Models for Mycobacterium avium subsp. paratuberculosis. Veterinary Immunology and Immunopathology. 2020. URL: https://www.semanticscholar.org/paper/29c35235ebfadbdc10dd2e85b86cc35833330ee0
[21] Cochard T, Branger M, Supply P, et al. MAC-INMV-SSR: a web application dedicated to genotyping members of Mycobacterium avium complex (MAC) including Mycobacterium avium subsp. paratuberculosis strains. Infection, Genetics and Evolution. 2019. URL: https://www.semanticscholar.org/paper/8b87772092729fb457e66b170e043aaa164674ea
[23] Cunha MV, Rosalino L, Leão C, et al. Ecological drivers of Mycobacterium avium subsp. paratuberculosis detection in mongoose (Herpestes ichneumon) using IS900 as proxy. Scientific Reports. 2020. URL: https://www.semanticscholar.org/paper/3bbe918ed2235175ad8ce9bace8b070c87c9f743
[24] Čurlík J, Lazár P, Iglódyová A, et al. Detection of Mycobacterium avium subsp. paratuberculosis in Slovakian wildlife. Polish journal of veterinary sciences. 2020. URL: https://www.semanticscholar.org/paper/967b24f987747f03beb8c7b0632583b2e57c4779
[25] Puerto-Parada M, Arango-Sabogal J, Paré J, et al. Risk factors associated with Mycobacterium avium subsp. paratuberculosis herd status in Québec dairy herds. Preventive Veterinary Medicine. 2018. URL: https://www.semanticscholar.org/paper/2f5286846b0e3d18573cc3ecfc4d6b6cbdfe72ca
[26] Samba-Louaka A, Robino E, Cochard T, et al. Environmental Mycobacterium avium subsp. paratuberculosis Hosted by Free-Living Amoebae. Frontiers in Cellular and Infection Microbiology. 2018. URL: https://www.semanticscholar.org/paper/430ef7f94854714335264ee51489579769f5c416
[27] Bates A, O’Brien R, Liggett S, et al. Control of Mycobacterium avium subsp. paratuberculosis infection on a New Zealand pastoral dairy farm. BMC Veterinary Research. 2019. URL: https://www.semanticscholar.org/paper/9ce0446911d80ee1e0f761b7f0aea70a6e82a036
[28] Koets A, Ravesloot L, Ruuls R, et al. Effects of Age and Environment on Adaptive Immune Responses to Mycobacterium avium subsp. paratuberculosis (MAP) Vaccination in Dairy Goats in Relation to Paratuberculosis Control Strategies. Veterinary Sciences. 2019. URL: https://www.semanticscholar.org/paper/3aec21c051c97a4863661aaa20e6b9a861b93535
[29] Cirone K, Lahiri P, Holani R, et al. Synthetic cathelicidin LL-37 reduces Mycobacterium avium subsp. paratuberculosis internalization and pro-inflammatory cytokines in macrophages. Cell and Tissue Research. 2019. URL: https://www.semanticscholar.org/paper/be230ddadf2c71b46951a4a3d9a243f33ab659a7
[30] Nowotarska SW, Nowotarski K, Grant I, et al. Mechanisms of Antimicrobial Action of Cinnamon and Oregano Oils, Cinnamaldehyde, Carvacrol, 2,5-Dihydroxybenzaldehyde, and 2-Hydroxy-5-Methoxybenzaldehyde against Mycobacterium avium subsp. paratuberculosis (Map). Foods. 2017. URL: https://www.semanticscholar.org/paper/58bd2f94f8140f5adb08da4ad0529f8dc03611f1
[31] Steuer P, Tejeda C, Martínez O, et al. Effectiveness of copper ions against Mycobacterium avium subsp. paratuberculosis and bacterial communities in naturally contaminated raw cow’s milk. Journal of Applied Microbiology. 2020. URL: https://www.semanticscholar.org/paper/d798b83a1a30dd819c70177e4ff84e3cebcce8b7
[32] Hruška K, Bartoš M, Kralik P, et al. Mycobacterium avium subsp. paratuberculosis in powdered infant milk: paratuberculosis in cattle - the public health problem to be solved. 2018. URL: https://www.semanticscholar.org/paper/f72ef358b7ea1574cdeca94ac7a340f767a098b6
[33] Slana I, Paolicchi F, Janštová B, et al. Detection methods for Mycobacterium avium subsp. paratuberculosis in milk and milk products: A review. 2018. URL: https://www.semanticscholar.org/paper/7c61f68561c7386413c092195232b1eb3c65c5a3
